DXF or Print File, Kawasaki KRX 1000 Windshield Frame (fits 2020-2023)

Build your own Windshield for a fraction of the cost.

This sale is for your choice of a digital DXF file or a 1:1 Printed design  to build a custom windshield for a 2020-2023 Kawasaki 1000 with Stock Roll Cage . This frame is built from 1/8 inch thick aluminum sheet although other materials can be used . The frame will fit on a piece of 45" wide x 30" high aluminum sheet. The DXF is designed for direct upload and use with cnc plasma or laser cutters.


The DXF File Provided is for the frame only with vent holes on the right and left side for ventilation. We do have a design available without these holes programmed in.

This dxf file can be uploaded into many programs to make any changes needed or uploaded direct to send cut send or another company for laser or plasma cutting.

This sale includes the following:

1 DXF file (Windshield Frame)
1 Parts list to complete the windshield

or

1 1:1 Printed Copy of Frame to be used as a template

1 Parts list to complete the windshield

After Checkout you will receive an email containing the DXF file
